Counterbalanced Electric Stacker 1200lbs (118" High)

The Counterbalanced Electric Stacker

Dimensions

• Overall Length: 78.8"
• Overall Width: 33.3"
• Recommended Aisle Width: 108.3" (9 feet)
• Turning Radius: 46.1"
• Load Center: 15.7"
• Gradeability (Laden/Unladen): 6% / 10%

Motor Specifications

• Drive Motor: 650-watt
• Lift Motor: 2,200-watt
• Battery: GEL, rechargeable, maintenance-free
• Service per Charge: 4-5 hours (two 12-volt, 105Ah rechargeable GEL batteries)
• Charger: 24V/10A built-in charger

Operational Features

• Perfect for approaching racks and trucks, with no straddle legs obstructing the approach
• Upright walking function, ideal for narrow aisles
• Quick 2-minute wheel replacement, thanks to the upper horizontal structure design
• The Best Choice for Narrow Sites

Forks

• Thickness: 1"
• Width: 3.9"
• Length: 37.4"
• Fork Width Range: 8.6" - 25.4"

Mast

• Mast Height (Lowered): 80.8"
• Mast Lifting Height: 118"
• Mast Height (Raised): 143.3"
• Mast Tilt (Forward/Backward): 1° / 3°

Speed

• Lifting Speed (Laden/Unladen): 6.7/9.8 inch/s
• Lowering Speed (Laden/Unladen): 5½/5½ inch/s
• Travel Speed (Laden/Unladen): 2½/2.8 mph

Features

• Long handle structure makes truck steering light and flexible
• Thoughtful mast design for wide viewing angles

Important Notes

• Not explosion-proof
• Designed for use on flat ground, avoid uneven surfaces, potholes, or large ramps
• Normal ambient temperature range: +104°F to -13°F
• Battery Care: Fully charge battery before use to avoid damaging cells
• Charger: Plugs into standard 110V-120V outlets
• Maintenance: Charge forklift once a month, even if not in use
